Home Products Pot Mill
Pot MillKey Feature
Pot MillKey Feature
COD not available
Pot Mill

Pot Mill

Share with
Share this on :

Description

Product details

Pot Mill Key Features • Vibration free sturdy design. • Smooth motor operation due to VFD control. • Rotation in clockwise and anticlockwise direction.

Keywords

  • Filter tags

Other Products

Related Products

Material of construction Structure: Powder coated MS, heavy duty structure Rollers: Rubber coated MS rollers No. of tiers 3 Roller length -customised as per customer's requirment Roller adjustment Fixed rollers. If required, manual distance adjustment between the two rollers can be designed for accommodating smaller containers. Control Panel Separate control panel for each tier consisting of VFD, RPM indicator, switches etc. Panel will be made up of Flameproof material Motor AC induction motor, Make: Hindustan or equivalent Motor Capacity - as per load requirement RPM -Digital RPM indicator RPM control- Variable RPM RPM range Upto 250 RPM VFD 2 HP capacity, Make: Delta or equivalent Gearbox - Reputed international make Timer -Can be set upto 99 hours
View Details
Three Tier Jar mill
This advanced laboratory equipment is designed for powder compaction using cold isostatic pressing—a method that applies uniform hydraulic pressure to shape powders into dense, crack-free green bodies. It’s ideal for research labs, material testing, and precision manufacturing. ⚙️ Key Features & Components - Uniform Compaction with Oil: - Uses high-pressure hydraulic oil to transmit force evenly across the powder compact. - The pressure medium surrounds the die from all sides, ensuring isostatic compaction. - Eliminates air voids, increases green strength, and improves dimensional accuracy. - Robust Construction: - Mounted on a blue steel frame with wheels for easy mobility. - Includes a stainless steel pressure vessel, hydraulic cylinders, and a control panel. - Customizable Design: - Offers custom die options made from tool steel. - Flexible die-release systems available in multiple sizes. - Rated for pressures up to 300 MPa, ensuring precise shaping and high mechanical strength. - Control Panel: - Allows for precise adjustment of pressure settings and operation timing. - Designed for clean, reliable, and repeatable performance. 🧩 Applications - Powder metallurgy - Ceramic and composite material research - Advanced material prototyping - Green body formation for sintering
View Details
Laboratory CIP
PRODUCT INFORMATION SIEVE SHAKER Model: Table Top Type: Digital/ Analog Power Source: Electric Timing Setting Range: Programmable Time 1min to 60min Capacity: Up to 8 Sieves with Lid and Receivers. Voltage: 220V Frequency: 50 to 60Hz Sieve Diameter: 200mm Sieving Actions: Horizontal and Vertical Sieving Action MOC: Stainless Steel/ Mild Steel Mode of Operation: Analog/ Digital
View Details
Sieve Shaker
